Cast Iron Swing Check valve
3790 INR/Piece
Product Details:
- Size 40MM-200MM
- Structure Check
- Usage Water Line
- Color GREY
- Product Type Swing Check valve
- Material Cast Iron
- Power Manual
- Click to View more
X
Cast Iron Swing Check valve Price And Quantity
- 1 Piece
- 3790.00 - 37101.00 INR/Piece
- 3790 INR/Piece
Cast Iron Swing Check valve Product Specifications
- Cast Iron
- Swing Check valve
- Manual
- High Pressure
- GREY
- Water
- Check
- 40MM-200MM
- Water Line
- Straight Pttern
Cast Iron Swing Check valve Trade Information
- Cash Against Delivery (CAD) Cash on Delivery (COD) Cash in Advance (CID) Cheque Cash Advance (CA)
- 50000 Piece Per Month
- 1 Week
- Asia
- All India
- BS 5153
Product Description
Specification
- Product Name : Cast Iron Swing Check valve
- Product Standard : BS 5153
- Type of Pattern : Straight Pattern
- Product Description : Bolted Cover
- Type of seat & Disc : Renewable
- Trim : Stainless Steel (AISI 410)
- Stud, Nut & Washer : Carbon Steel as per IS 1367
- Locking Screw : Stainless Steel as per AISI 304
- Gasket : Steam Joining Sheet as per IS 2712 Gr. W/3
- Pressure Rating : Class 125
- Hydraulic Test Pressure : Body 21 Kg/cm², Seat 14 Kg/cm²
- Working Pressure : Max. BOP 10.54 Kg/cm²
- Working Temperature : Max. 220°C
- End Details : Flanged ends as per BS 16.1 CL-125 Flat face.
Technical specification
Trims | Stainless Steel (AISI 410) |
Size | 40MM |
Model Name/Number | PV-106 |
Brand | KRANTI |
Material | Stainless Steel |
Color | Silver |
Certification | IBR Approved |
Type | Swing check valve |
Media | Water |
